Details
The AccuRAID AR442F4 series is a high density 4U rackmount designed for storage hungry applications, and accommodates up to 84TB of storage space. The unit utilizes advanced Fibre technology when operating as direct attached storage (DAS), and could be setup as a storage area network (SAN) with the assistance of a Fibre Channel network switch. In addition, the duo Fibre Channel ports allow the support of clustering, where the unit could be accessed by multiple servers, ensuring continuous uptime in a production environment.
To reinforce the AR442F4's ability to overcome hardware failure, three redundant and hot-swappable power supplies and two hot-swappable cooling fans are available for added safeguard. Single controller (AR442F4) or Active-Active redundant controllers (AR442F4R) options are available for further failure protection when needed. Internally, the AR442F4 supports up to RAID 6, with RAID monitoring, RAID notification, automatic failover, and automatic recovery. The unit's built-in Ethernet port with web based management console and SES management features provide instant access to the status of the RAID array and the enclosure to reduce downtime.
Features:
To reinforce the AR442F4's ability to overcome hardware failure, three redundant and hot-swappable power supplies and two hot-swappable cooling fans are available for added safeguard. Single controller (AR442F4) or Active-Active redundant controllers (AR442F4R) options are available for further failure protection when needed. Internally, the AR442F4 supports up to RAID 6, with RAID monitoring, RAID notification, automatic failover, and automatic recovery. The unit's built-in Ethernet port with web based management console and SES management features provide instant access to the status of the RAID array and the enclosure to reduce downtime.
Features:
- 4U 42-bay 84TB Fibre Channel system.
- Redundant Active / Active-Failover RAID controllers provides extra redundancy and availability.
- Complete modular designs on controllers, cooling fan and power supply to provide automatically failover and recovery.
- Supports up to RAID 0,1,1+0,5, and 6.
- Supports two servers / applications failover clustering by providing dual Fibre Channel ports to hosts, or supporting even more than two servers by utilizing Fibre Channel switches. Provides building blocks for SAN solution.
- High density design leveraging low-cost / high-capacity SATA II disks for storage hungry applications. A major element for SAN-sharing applications.
- Maxmiun LUNs: up to 1024.
- Online RAID expansion.
- Support global / local hot spare and automatic hot rebuilding.
- Optional battery backup.
- Model: AR442F4R
- Form Factor: 4U Rackmount
- HDD Trays: 42 Hot-Swappable 3.5"
- RAID Level: 0, 1, 0+1, 3, 5, and 6
- Maximum Capacity: 84TB
- CPU: AMCC 440SPe
- Memory: 1GB, Upgradable to 4GB DDR-2 ECC SD-RAM Memory
- Auto Rebuilding: Yes
- Hot-Spare: RAID 1, 1+0, 5, 6
- Host Interface & Transfer Rate: Dual Fiber Channel (4 Gbps)
- Drive Interface: SATA II
- Cooling Fan: 2 x Blower Fans
- Power Supply: 600W x 3 Redundant Power Supply Modules
- Control Interface: LCD Panel, RS232, RJ-45 Ethernet
- Status Indicators: 1 LED / HDD
- Dimension (in): 7"H x 19"W x 30.7"D
- Limited Watrranty: 2 Years
